Goldwave based Tutorial
This tutorial group by the 86 school TeliuTe Xinjiang Production
This tutorial group by the 86 schools in Xinjiang TeliuTe productionall copyright, commercial use, please contact the author
Tutorial Network: http://www.laxjyj.com/teliute/ First, run the program
Goldwave is a music editing software, compact, easy to handle music files fine, following a practice we learn how to run it;
finished version of the file, you can Free Software download, common teaching aids can also be downloaded: http://www.laxjyj.com/teliute/jiaoju/index.htm
1, start Goldwave
1) Click on Goldwave icon on the desktop or in the installation folder, double-click Goldwave icon, you can run Goldwave;
2) for the first time will start with a prompt, here point “is” to automatically generate a current user preference files;
3) after successfully entering a gray blank window, next to a dark red controller window, it is used to control playback;
2, open the file
1) Click the toolbar button on the second “Open” button in the Open dialog box, select out of a music file, open it;
lesson images folder in a m1 file, can be used as practice;
< br />
2) open the file, the window out of the middle color of the sound waves, that is the middle of two two-channel stereo, the following length of time the music, the right of the playback control can also be used;
green triangle is the play button, the blue box is stopped, the following two vertical line is suspended, the red dot is the record button;
3) Tap the green play button, a window appears to move the pointer to indicate the current playback position, the right of the controller shows the exact time;
3, practice
1) Open the music file a note of music m1 length;
2) play about music files, music in 2.6 seconds at the pause, then resume playback;
This section to learn the basics of using Goldwave, if you understand and successfully completed the exercise, continue with the next lesson content;
Second, the volume adjustment times
Music volume is too high or too low, need to be adjusted, in Goldwave, there is a menu you can modify the effect, let look at an exercise;
1, start Goldwave
1) Click on the icon on the desktop Goldwave, or in the installation folder, double-click Goldwave icon, you can run Goldwave;
2) for the first time will start with a prompt, here point “a” can automatically generate a current user preference files;
3) after successfully entering a gray blank window, next to a dark red controller window, which is used to control playback;
2, adjust the volume
1) Click on the second toolbar button “Open” button in the Open dialog box, select out of a music file, open it;
lesson images folder m1 in a file that can be used as a practice;
2) point the menu” effect – volume – change volume “command, a dialog box out:
out of the dialog box in the upper right-click on the drop-down button, select -6.0206 negative is to reduce the volume, you can also enter their own;
point below the green play button, listen to what effect, then “OK” to return window, the waveform can be found in smaller;
3) point “File – Save As” to m1a for the file name, save the file to own folder,
In addition to adjust the volume, you can also select the beginning and set fade in, fade out the end of the set;
learn to adjust the volume in this section the basic method, if you understand and successfully completed the exercise, continue with the next lesson content;
Third, format conversion
common music formats are Mp3, wma, wav, rm, etc., usually they have their own advantages, which are used in different occasions, the following exercises to learn how we convert format;
1, start Goldwave
1 ) Click on the icon on the desktop Goldwave, or in the installation folder, double-click Goldwave icon, you can run Goldwave; 2) for the first time will start with a prompt, here point “is” you can automatically generate a current user preset file;
3) after successfully entering a gray blank window, next to a dark red controller window, which is used to control playback;
2, Format conversion
1) Click on the second toolbar button “Open” button in the Open dialog box, select out of a music file, open it;
the class images folder in a m1 file, can be used as practice;
2) point of menu “File – Save As ..” command, out of a save dialog box, first in the top of the “Save In the “find their own folder;
from the bottom of the “Save as type” can be seen in the wma format, we need to convert it to mp3 format;
3) In the Save as type drop-down button next to the tap, select the Mp3 format;
4) and then in the bottom of the “sound”-click on the button next to select the “Layer-3, 22050 Hz, 48Kbps, Stereo”
5) After a good choice, point “Save” button, you can create a Mp3 file format m1 in out of the confirmation dialog box, click “Yes”;
This section to learn basic music format conversion method, if you understand and successfully completed the exercise, continue with the next lesson content;
Fourth, the interception of music
Sometimes we just need to fragments of music, in GoldWave is how does it work? Here we look at a practice;
1, start Goldwave
1) Click on the icon on the desktop Goldwave, or double-click Goldwave installation folder icon, you can run Goldwave ;
2) for the first time will start with a prompt, here point “is” you can automatically generate a current user preference files;
3) well into the after a gray blank window, next to a dark red controller window, which is used to control playback;
2, the interception of music start Goldwave
1) Click on The second toolbar button “Open” button
, in out of the open dialog box, select a music file, open it;
images folder in this lesson are a m1 file, can be used as practice;
2) At this time all the music is selected, we intercept the third grid out point left is to choose the starting point;
aim of the third grid cell on the left click button, so the first two cells on the grayed out;
3) in the first three cell lines knocked right the right frame, select the second “set the end of the mark”;
so that you can select the third frame, the other part is gray ;
4) point of menu “File – Save the selected part of the ..” command to m1c for the file name, format change, save the file to its own folder;
5) If you want to intercept a certain period accurate music, music in the Control Panel, click the “Pause” button to pause the music, then the menu “Edit – Mark – put start tag”;
and then continue playing, to the position, the same point again,” put an end tag “, which also can select the good;
If you know the playing time, you can choose the above “set the mark ..” command, the start and end times can fill up;
this section to learn the basic methods of interception of a piece of music, if you understand and successfully completed the exercise, continue with the next lesson content;
five , channel separation
Sometimes we need to keep the song in the music part down, if this music is stereo, then the two channels can be individually saved down, let look at an exercise;
1, start Goldwave
1) Click on the icon on the desktop Goldwave, or in the installation folder, double-click Goldwave icon, you can run Goldwave;
2) for the first time will start with a prompt, here point “is” you can automatically generate a current user preference files;
3) after successfully entering a gray blank window next to a dark red controller window, which is used to control playback;
2, the interception of music start Goldwave
1) click on the toolbar of the second button “Open” button in the Open dialog box, select out of a music file, open it;
lesson images folder m1 in a file that can be used as a practice;
2) point of menu “Edit – Mono – Left channel”
3) this time in the middle of the panel, only selected waveform in the above green, below the red wave is gray;
4) point of menu” File – Save As .. selected part of the “command to m1d as file name and save the file to your folder;
this section to learn the music to save a single channel approach, if you understand and successfully completed the exercise, continue with the next lesson content; < br />
six, how to record
In this section we study the recording in GoldWave operate, we are generally in microphone for voice recording, let look at a practice;
1, start Goldwave
1) Click on the icon on the desktop Goldwave, or in the installation folder, double-click Goldwave icon, you can run Goldwave;
2) The first will start with a prompt, here point “is” you can automatically generate a current user preference files;
3) after successfully entering a gray blank window, next to the a dark red of the controller window, which is used to control playback;
2, a new blank document
1) point of menu “File – New” out of a dialog ;
the second sampling rate to 22050, the following time to 5 minutes, click “OK” to return, out of a blank document window ;
2) point the menu “Options – control attributes ..”, out of a panel, in the third label “volume” on tap;
input device in the middle of the panel, select the bottom of the “microphone” tick check, that is, from the microphone in the recording, click “OK” to return;
3) the microphone into the computer, the red plug into the red jack,
then Goldwave right side of the control panel, click the red dot of the “Record” button
, then speak into the microphone on it;
Click the red square button to stop the two vertical lines is to suspend the recording;
4) If the recording volume is too small, can go to the “Volume Properties” to modify;
① lower right corner of the taskbar double-click on the small speaker icon to open the volume properties;
② point menu “Options – Properties” command, out of a panel, in the middle select “recording”, tick below the microphone, the other to remove, click “OK” to return;
< img src = "http://simg.sinajs.cn/blog7style/images/common/sg_trans.gif" onClick = "window.open ( ttp://simg.sinajs.cn/blog7style/images/common/sg_trans. gif "onerror =" this.src = http://cache.soso.com/img/blog/p1.gif quot;onload =" addjustimg (this) "width = 342 height = 400 TYPE =" audio / mpeg ">
③ and then point the menu” Options – Advanced Control “command in the panel below it an” Advanced “button, click the button;
④ to below 1 Mic Boost check selected so that the volume will increase the number of recordings, points off back panel, the volume due to lower;
This will adjust the volume, return Goldwave can continue recording;
using Goldwave this section to learn the basic operation of recording, if you understand and successfully completed the exercise, continue with the next lesson content;
seven, noise reduction
recording with microphones tend to have some background noise, noise reduction in GoldWave, there is a command, you can filter out some noise, let look at a practice;
1, start Goldwave
1) Click on the icon on the desktop Goldwave, or in the installation folder, double-click Goldwave icon, you can run Goldwave;
2) The first will start with a prompt, here point “is” you can automatically generate a current user preference files; 3) after successfully entering a gray blank window, next to a dark red controller window, It is used to control playback;
2, the interception of music start Goldwave
1) Click on the second toolbar button “Open” button
< br />
, in out of the open dialog box, select a music file, open it;
images folder in this lesson are a m2 file, can be used as practice, Local download;
can be found between the two sound waves have some jagged noise;
2) the method selected with the mouse to drag noise at the beginning of that period, then the menu “Edit – Copy” command;
3) points on the toolbar of the” Select All “button, select all the sound waves, that is, All sound waves for noise reduction;
4) point menu “effect – Filters – Noise Reduction ..” command, out of a panel;
5) out of the panel at the left point down to the” clipboard “, then” OK “button to return to the window;
< img src = "http://simg.sinajs.cn/blog7style/images/common/sg_trans.gif" onClick = "window.open ( ttp://simg.sinajs.cn/blog7style/images/common/sg_trans. gif "onerror =" this.src = http://cache.soso.com/img/blog/p1.gif quot;onload =" addjustimg (this) "width = 445 height = 414 TYPE =" audio / mpeg ">
window waveform can be found, those jagged noise is gone, point to the right controller in the green play button to hear a very clear voice;
< br />
to m2a for the file name, save the file to its own folder;
this section to learn the basic methods of noise reduction using Goldwave, if You understand and successfully completed the exercise, continue with the next lesson content;
eight, rip tape
Sometimes we need to rip the text of the tape to the computer, use GoldWave recording function can be achieved, let look at a practice;
1, start Goldwave
1) Click on the icon on the desktop Goldwave, or in the installation folder Double-click Goldwave icon, you can run Goldwave;
2) for the first time will start with a prompt, here point “is” to automatically generate a current user preference files;
3) after successfully entering a gray blank window, next to a dark red controller window, which is used to control playback;
2, connected to the computer and tape recorder
1) to find one pair of recorded lines, two are the same as the stereo plug, you can own a bad headphone cable to the two together;
2) to a receiving recorder headphone output, one to the computer microphone input jack on the red;
3) Another connection is connected in the tape recorder on the Line Out (line out) jack on the computer connected Line in jack (usually in the back of the case), “volume control” inside the recording tick Line in;
3, recording
1) create a new in Goldwave file, you can use 22050 and five minutes as the recorder adjust the volume;
2) put about a tape, then the record button, and then record a short stop to see the waveform, under the effect of audition; < br />
because it is recording from a microphone, tape recorders do not have the volume too high, try several times, to find the right volume;
this section to learn the basic method of ripping tape, if you understand and successfully completed the exercise, continue with the next lesson content;
nine, the music recording computer
sometimes met with some good music or online movie, you can use GoldWave recorded, let look at an exercise;
1, start Goldwave
1) Click on the icon on the desktop Goldwave, or in the installation folder Double-click Goldwave icon, you can run Goldwave;
2) for the first time will start with a prompt, here point “is” to automatically generate a current user preference files;
3) after successfully entering a gray blank window, next to a dark red controller window, which is used to control playback;
2, set up recording equipment
1) Click “Start – All Programs – Accessories – Entertainment – Volume Control”, the lower right corner of the screen can also double-click on the small speaker;
2) points menu “Options – Properties” command, out of a panel, in the middle select “recording”, mixed in stereo Stereo Mix the following to check the other remove the “OK” to return;
3) the volume slider to adjust the size, can be minimized, and then recorded some lyrics adjusted;
3, recorded music
1) create a new music file in GoldWave, usually songs you can use 22050 and 5 minutes, then the red record button;
2) play music files, so that Goldwave can be recorded, and recorded look good and save the file;
this section to learn computer using Goldwave to record the basic method of playing music, if you understand and successfully completed the exercise, continue with the next lesson content;
ten, falling tone
single article word for space limitations, omit the release. See: http://www.laxjyj.com/teliute/TeacHtm/gw/lesson10/ lesson10.html
